What is the EA888 engine?
The EA888 is a four-cylinder turbocharged gasoline engine created by the Volkswagen Group. It was first used in 2004 but has evolved with various enhancements since then. The engine became popular due to its spectacular performance in vehicles from brands such as Volkswagen and SEAT.
EA888 engine specifications and design
The EA888 engine has several variations, each designed with different specifications. In general, however, the engine is known for its:
- Lightweight construction – It is made of cast iron, which is lighter than the previous cast-iron block.
- Turbocharging – Its single-scroll turbocharger increases power output and throttle response.
- Direct injection – This delivers fuel directly into the combustion chamber for improved fuel efficiency and reduced emissions.
- Dual overhead camshaft – A DOHC valvetrain improves engine breathing for greater control over the engine’s valve lift and timing.
- Electric wastegate – This improves the turbocharger response, reducing turbo lag.
- Engine management system – A Bosch MED17 engine management system controls the engine’s ignition timing and fuel injection to optimize efficiency and performance.
Below are the specifications for the latest version of the EA888, the Gen3B:
- Configuration: Inline four-cylinder
- Displacement: 2.0 liters
- Valvetrain: DOHC (dual overhead camshaft
- Turbocharger: Single-scroll turbocharger with an electric wastegate
- Fuel delivery: Direct injection
- Power output: 228 horsepower at 4700-6200 rpm (US version)
- Bore x stroke: 82.5 mm x 92.8 mm
- Torque: 258 lb-ft at 1500-4500 rpm (US version)
- Engine block: Cast iron
- Compression ratio: 9.6.1
- Engine management system: Bosch MED17
- Cylinder head: Aluminum alloy
