Name: Siemens SIRIUS Industrial Control Panels
SKU: 31460
Availability: InStock

Siemens SIRIUS Industrial Control Panels

£2,000.00

Technical Details

The PMC523 is a 16 port RS-422 serial controller with a PCI bus 2.3 target interface compliant up to a 33 MHz clock with a 32-bit bus. The ports are accessible via a front 68-pin high-density connector or rear I/O via P14. Flow control is either automatic RTS/CTS or DTR/DSR. Xon/Xoff software flow control is automatic as well.

Description

Siemens–a provider of automation and digitalization in the process and manufacturing industries–and Allied Electronics & Automation (Allied)–a high-service distributor of automation and control, electronic, electrical, mechanical, and maintenance products for suppliers–are teaming up to help panel builders better design simpler, more flexible and space-saving industrial control cabinets. Siemens’ SIRIUS modular system, now available from Allied, offers a full range of modular industrial control panel components in seven compact standard sizes, including devices needed to switch, protect, control and monitor motors from size S00 to S12 (45mm to 160 mm in width), and power ratings from 4 to 335 HP (3 to 250 kW).

Key considerations for building control cabinets include wiring time, saving panel space, and whether components meet national regulations and industry codes. Because the panel can contain different-size motor starters, the consistency offered by the manufacturer is important. With SIRIUS, CAx data is available throughout, and users can draw on comprehensive, standard-compliant configuration support to simplify workflows and speed up the electrical engineering process.

From motor starter protectors to overload relays, soft starters and contactors, SIRIUS components are compact and designed for quick and easy connection to facilitate industrial control panel maintenance. The modularity and ease of use of the system also provides engineers with significant advantages when designing and building new control cabinets. SIRIUS devices also benefit from more than 50,000 combination tests and approvals, making them suitable for worldwide deployment.

“We put a lot of thought into the modularity of our designs,” says John Burns, Application Resource Center Manager at Siemens. “For example, with the typical comb busbar system you might have four starters side-by-side and starter three goes down. Typically, to replace it you need to do quite a lot of disconnecting. With SIRIUS, we added an easy plug-in module with a backplane that provides touch-safe 3-phase power across the busbar system, making it quick to assemble, easy to design in, and allowing it to carry the same power rating as the comb busbar system. If one starter fails, the end user can easily switch out that one starter and leave the others under power with this touch-safe design. This can reduce downtime significantly because you don’t need to bring the whole panel to a stop.”

Allied helps engineers, purchasers, maintainers, fleet and facility managers, and inventors build, maintain, and renew their machinery and technology and is an authorized distributor for Siemens products. In addition to SIRIUS, Allied stocks a full range of Siemens control, switching and protection products for industrial control panel builders, and publishes a control panel component guide, as well as expert advice on topics ranging from motor switching and protection to industrial control technology.

The PMC523 is a flexible solution and a technology insertion which integrates multiple serial I/O channels onto single board computers (SBCs) with PCI Mezzanine Card (PMC) sites. Its efficient design packages 16 serial channels onto a single PMC. Additionally, this serial controller utilizes dual octal UARTs to increase overall performance through reduction of programmed I/O operations. This provides an evolutionary path for enhanced software and ultimately protects customers who have already designed systems utilizing the previous generation PMC423.

The SPR518 provides an upgrade path for customers by offering a replacement for the existing SPR418A. This card is a short form factor PCI Express (PCIe®) carrier for XMC modules which allows for use with traditional PCs. The PCIe interface provides for unimpeded data transfers at the full rate supported by the mezzanine card and is enhanced by a PCIe Gen3 Redriver. This enhancement allows for safe operation of XMC modules on PCIe mainboards, where previously the SPR418A could only support Gen2.

Pete Thompson, VP of Product Management for Abaco said, “Abaco’s commitment to our customers expands beyond the life cycle of one product, and innovation doesn’t stop after it hits the market. Our team listens to our customers’ needs to develop solutions that will outpace current products and provide an upgrade path to avoid obsolescence in the long run. Both the PMC523 and SPR518 are evidence of that commitment, as they each deliver a clear upgrade path with solutions that will enable our customers to succeed.”
